IR Ovens
fast_bake_oven.pdf
The Heatlight Infrared Drying System makes short work of drying finishes on wood & metal, providing instant heat & reducing drying time from hours to minutes. The Heatlight infrared drying system from Victory has been designed to meet the needs of busy manufacturers that need to quickly dry painted or coated wood and metal.
Victory has a long history of developing infrared products for a variety of industries, including automotive and plastics. This new system now draws on this experience to offer a much-needed solution for fast, efficient drying of finishes on wood & metal products such as doors, panels and window frames with minimal risk of contamination by dust.
Waiting for paint, varnishes and other finishes to dry slows down the manufacturing process, especially if products that need to be sprayed must wait for other items to dry first. The Victory system means that the drying cabinet can be located away from the spraying or painting area. The mobile racking can be loaded with product and simply wheeled away, into the drying cabinet.
Product Features
Instant Heat
The system provides immediate heat with no warm-up time, improving efficiency and reducing downtime during operations.
Fast Drying Time
The quick heat-up feature leads to faster drying times, ensuring rapid completion of processes like paint drying and curing.
Mobile Racking
The mobile racking system makes it easy to move items in and out of the oven, improving workflow and convenience in industrial applications.
Standard FBO range
| Code | Width (mm) | Depth (mm) | Height (mm) | Watts (w) |
| FBO1 | 1650 | 1100 | 2000 | 4 x 1500 |
| FBO2 | 2200 | 1100 | 2000 | 5 x 1500 |
Voltage: 220-240V ~ 50-60Hz
Supplied in a flat pack format with easy-to-follow assembly instructions, each Fast Bake Oven is supplied with 4 x 1500W heater cassettes — each mountable in three standard height positions for your own unique application. The cassettes are fully dimmable, allowing you the flexibility to control your heat requirements for individual job. The Fast Bake Oven is not supplied with any controllers as standard due to the many variable customer needs. However, optional controllers are available.
